100mm Heaveguard - Expanded Polystyrene Board Used Against Ground Heave - 2400mm x 1200mm
Guide Price
100mm Heaveguard - Expanded Polystyrene Board Used Against Ground Heave - 2400mm x 1200mm
Guide Price: £45.00 (£54.00 inc VAT)
Price per m2: £15.63/m2 (£18.75 inc VAT)
- Product Code: A1-3743
- Delivery Time: 2 - 3 working days
- Brand: Cordek (Tech. support: 01403799600)
- Model: 2400x1200mm - 2.88m2
Our ratings on 28-08-2026:
4.8 out of 5
100mm Heaveguard - Expanded Polystyrene Board Used Against Ground Heave - 2400mm x 1200mm
Width: 1200mm
Length: 2400mm
Board Coverage: 2.88m2
100mm Heaveguard is a compressible low density Expanded Polystyrene (EPS) board, used when foundations need to be protected against ground heave and against lateral heave. Heaveguard is used to prevent potential problems in foundations due to moisture movement in soils, such as clay heave, reducing pressure on ground beams in piled foundations, and on the sides of trench fills. The expansion and contraction process during wet and dry periods is known as clay heave and this can cause severe problems with foundations. Heaveguard can be used as permanent shuttering for cast in-situ reinforced concrete.
APPLICATION
- When foundations need to be protected against ground heave and against lateral heave.
CHARACTERISTICS
- A rapid, cost effective solution to clay-heave problems,
- The initial compression of the material during casting can be disregarded,
- It is rot-proof and durable and will withstand the conditions encountered below ground,
- It will not degrade in the presence of high levels of ground water or precipitation.
CERTIFICATION
- BBA Certified - Certificate number 17/5448.
Heaveguard_data_sheet.pdf
Brand: Cordek
Model: Filcor 140 - max. size: 1200x2400mm
Delivery Time: 1 - 2 days
Filcor 140 EPS (Expanded Polystyrene) is used as a lightweight structural fill alternative to more traditional fill materials or as a lightweight void former in structural concrete. It can be used up to 5600mm thick of 25kN/m3 concrete above it.Filcor Expanded Polystyrene (EPS) is a lightweight stru..
Brand: Cordek
Model: 1200mm x 2400mm - 2.88m2
Delivery Time: 3 - 5 days
270mm Cordek Cellvent HX - Grade 9/13 is a product specially designed to provide foundation protection from ground heave effects whilst also providing an excellent gas venting medium when installed under reinforced concrete floor slabs where subsidence is not expected. Cellvent HX provides protectio..
Brand: Cordek
Model: HX B 85mm - 2.88m2
Delivery Time: 3 - 7 days
85mm Cellcore HX B Under Beam is specially designed to provide foundation protection from ground heave effects when installed beneath reinforced ground beams and pile caps. It is consisted of specially moulded hexagonal cellular Filcor expended polystyrene, available in a number of different de..
Brand: Cordek
Model: Filcor 70 - max. size: 1200x2400mm
Delivery Time: 1 - 2 days
Filcor 70 EPS (Expanded Polystyrene) is used as a lightweight structural fill alternative to more traditional fill materials or as a lightweight void former in structural concrete. It can be used up to 2800mm thick of 25kN/m3 concrete above it.Filcor Expanded Polystyrene (EPS) is a lightweight struc..
Brand: Cordek
Model: 220mm x 600mm x 600mm
Delivery Time: 2 - 3 working days
220mm x 600mm x 600mm Heaveguard Pile Collar is a compressible low density Expanded Polystyrene (EPS), used to support pile heads against lateral ground heave. It is a part of the Cordek Cellcore ground heave system. The pile collar will fit securely around the pile head to produce a square edge fo..
Guide Price
Brand: Cordek
Model: 2400x1200mm - 2.88m2
Delivery Time: 2 - 3 working days
50mm Heaveguard is a compressible low density Expanded Polystyrene (EPS) board, used when foundations need to be protected against ground heave and against lateral heave. Heaveguard is used to prevent potential problems in foundations due to moisture movement in soils, such as clay heave, reducing p..
Guide Price: £22.20
£26.64 inc VATRelated Products
Brand: Lemon Reinforcement
Model: 300mm x 150mm x 100mm
Delivery Time: 1 - 2 days
Heaveguard Fixing Pins are steel rebar stakes designed to secure Heaveguard ground‑heave protection boards in place during foundation preparation. The..
