40mm Isocheck ReVerb Wall Panel - 1200mm x 900mm - Various Colours

40mm Isocheck ReVerb Wall Panel - 1200mm x 900mm - Various Colours

Length: 1200mm
Width: 900mm
Thickness: 40mm
Board Coverage: 1.08m2
Weight/m2: 4.5kg
Weight: 4.86kg

40mm Isocheck ReVerb Wall Panel a high-performance acoustic absorption solution designed to effectively control reverberation and improve sound clarity within a wide range of interior spaces. This decorative panel would reduce echo and background noise, creating a more comfortable and intelligible acoustic environment in commercial, educational, leisure, and public buildings. Re-Verb Wall Panel features a core crafted from recycled material, specifically chosen for its exceptional sound-absorbing properties. This sustainable core is also Class 0 fire rated to BS476:Part 6, signifying excellent fire performance and contributing to overall building safety. The core is then faced with an aesthetically pleasing and durable fabric finish, available in a variety of colours and textures to complement diverse interior designs. The robust construction ensures both long-term acoustic performance and visual appeal. Installation of the Isocheck Re-Verb Wall Panel is straightforward, often utilising direct adhesive fixing or mechanical clips, allowing for flexible mounting on walls or even ceilings. These panels are suitable for a multitude of applications, including offices, classrooms, lecture theatres, sports halls, restaurants, and reception areas, where excessive reverberation can hinder communication and create an uncomfortable atmosphere.

Available colours:



CHARACTERISTICS

  • Faced with a durable fabric finish.
  • Available in a variety of colours and textures for aesthetic integration.
  • Core made from recycled material, specifically chosen for acoustic absorption.
  • Core Class 0 fire rated to BS476:Part 6, indicating excellent fire performance.
  • Effectively controls reverberation and reduces echo.
  • Enhances speech intelligibility and reduces background noise.
  • Robust construction ensures long-term acoustic performance and visual appeal.
  • Suitable for a wide range of interior spaces.
  • Contributes to improved concentration, enhanced communication, and overall occupant well-being.

APPLICATION

  • Offices, classrooms, lecture theatres, sports halls, restaurants, reception areas, and other commercial, educational, leisure, and public buildings.

INSTALLATION

  • Ensure wall surfaces are clean, dry, and free from decorative coverings.
  • Clip Fixing:
    • Lightly trace the panel edges onto the desired installation area.
    • Fix the appropriate number of clips using screws within the traced area.
  • Adhesive Application:
    • Spray contact adhesive horizontally onto the desired installation area on the wall.
    • Spray contact adhesive vertically onto the back of the panels, ensuring coverage over the clips.
    • Wait 2-5 minutes for the adhesive to become tacky.
  • Carefully align the panel to the marked area on the wall and gently push, allowing the clip spikes to engage with the back of the panel.
  • Once the panel is positioned correctly, press firmly over the entire surface to ensure maximum contact with the wall.
